Arduino Controlled Drawbot

DRAWBOT

image source: www.marginallyclever.com/

One of the highlights of the Vancouver Mini Maker Faire was Dan Royer’s drawbot kit in action. Dan sells his Drawbot kits online. The kit includes a 3D printed pen holder, 2 stepper motors, a 12V 2A power supply, 2x 3D printed bobbins, an Adafruit Stepper shield. The whole drawing bot is based on an Arduino UNO. The kit requires no soldering or wire cutting, and is perfect for use in a classroom.

Drawbot is even easier to use than any other machine of it’s kind. Choose a picture from your computer and the Java program will prepare it for you in 10 minutes or less. It also understands GCODE, the language used by 3D printers and industrial fabrication machines. You can even take the GCODE and send it to your RepRap or Makerbot.
